Description
Technical Specifications
| Model | DC-GSXC160601,DC-CAPF4961D6,DC-MBVC2000AA-1,DC-TX5N4 |
|---|---|
| UPC | 663051551152 |
| AHRI Number | 201522935 |
| Bundle Avg Coverage Area | 2,500 – 3,000 Sq Ft |
| Bundle Cooling Capacity | 5 Ton |
| Bundle Cooling Efficiency | 17 SEER |
| EER | 13 |
| Region Compatibility | Nationwide |
| California Residents | see Prop 65 WARNING |
DC-GSXC160601 Specifications:
| Model | DC-GSXC160601 |
|---|---|
| UPC | 663051551152 |
| Avg Coverage Area | 2,500 – 3,000 Sq Ft |
| Compressor | Two Stage |
| Cooling Capacity | 5 Ton |
| Electrical Phase | 1-Phase |
| Line Set Connection Type | Sweat |
| Liquid Line Size | 3/8 inch |
| Max Overcurrent Protection | 50 amps |
| Product Height (in) | 42.25 |
| Product Length (in) | 35.75 |
| Product Width (in) | 35.75 |
| Refrigerant | R-410a |
| Cooling Efficiency | 16 SEER |
| Suction Line Size | 1 1/8 inch |
| System Application Type | Central Split Systems |
| Voltage | 240 |
| Warranty | 10 Year Parts |
| Weight (lbs) | 326.0000 |
| Region Compatibility | Nationwide |
DC-CAPF4961D6 Specifications:
| Model | DC-CAPF4961D6 |
|---|---|
| UPC | 663051440425 |
| Air Flow Direction | Vertical |
| Cooling Capacity | 4 Ton, 5 Ton |
| Line Set Connection Type | Sweat |
| Liquid Line Size | 3/8 inch |
| Product Height (in) | 30 |
| Product Length (in) | 21.125 |
| Product Width (in) | 24.5 |
| Refrigerant | R-410a |
| Suction Line Size | 7/8 inch |
| Warranty | 10 Year Parts |
| Weight (lbs) | 76.0000 |
DC-MBVC2000AA-1-1 Specifications:
| Model | DC-MBVC2000AA-1-1 |
|---|---|
| UPC | 663051528086 |
| Blower Motor | Variable Speed |
| Cooling Capacity | 5 Ton |
| Electrical Phase | 1-Phase |
| Max Overcurrent Protection | 15 amps |
| Product Height (in) | 30 |
| Product Length (in) | 21 |
| Product Width (in) | 24.5 |
| Voltage | 240 |
| Warranty | 10 Year Parts |
| Weight (lbs) | 86.0000 |
TX5N4 Specifications:
| Model | TX5N4 |
|---|---|
| UPC | 681344941473 |
| Product Height (in) | 3.7 |
| Product Length (in) | 9.7 |
| Product Width (in) | 5.8 |
| Warranty | 1 Year |
| Weight (lbs) | 2.0000 |
