Description
Technical Specifications
| Model | GSXC180601,CHPF4860D6,MBVC2000AA,TX5N4 |
|---|---|
| UPC | 663051549326 |
| AHRI Number | 201522732 |
| Bundle Avg Coverage Area | 2,500 – 3,000 Sq Ft |
| Bundle Cooling Capacity | 5 Ton |
| Bundle Cooling Efficiency | 16 SEER |
| EER | 12.5 |
| Region Compatibility | Nationwide |
| California Residents | see Prop 65 WARNING |
GSXC180601 Specifications:
| Model | GSXC180601 |
|---|---|
| UPC | 663051549326 |
| Avg Coverage Area | 2,500 – 3,000 Sq Ft |
| Compressor | Two Stage |
| Cooling Capacity | 5 Ton |
| Electrical Phase | 1-Phase |
| Line Set Connection Type | Sweat |
| Liquid Line Size | 3/8 inch |
| Max Overcurrent Protection | 60 amps |
| Product Height (in) | 38.25 |
| Product Length (in) | 35.5 |
| Product Width (in) | 35.5 |
| Refrigerant | R-410a |
| Cooling Efficiency | 18 SEER |
| Suction Line Size | 1 1/8 inch |
| System Application Type | Central Split Systems |
| Voltage | 240 |
| Warranty | 10 Year Parts, Lifetime Compressor |
| Weight (lbs) | 296.0000 |
| Region Compatibility | Nationwide |
CHPF4860D6 Specifications:
| Model | CHPF4860D6 |
|---|---|
| UPC | 663051451827 |
| Air Flow Direction | Horizontal |
| Cooling Capacity | 4 Ton, 5 Ton |
| Line Set Connection Type | Sweat |
| Liquid Line Size | 3/8 inch |
| Product Height (in) | 24.5 |
| Product Length (in) | 21.125 |
| Product Width (in) | 26 |
| Suction Line Size | 7/8 inch |
| Warranty | 10 Year Parts |
| Weight (lbs) | 77.0000 |
MBVC2000AA-1 Specifications:
| Model | MBVC2000AA-1 |
|---|---|
| UPC | 663051528086 |
| Blower Motor | Variable Speed |
| Condenser/Coil Compatibility | 4 Ton, 5 Ton |
| Cooling Capacity | 4 Ton, 5 Ton |
| Electrical Phase | 1-Phase |
| Max Overcurrent Protection | 15 amps |
| Product Height (in) | 30 |
| Product Length (in) | 21 |
| Product Width (in) | 24.5 |
| Voltage | 240 |
| Warranty | 10 Year Parts |
| Weight (lbs) | 86.0000 |
TX5N4 Specifications:
| Model | TX5N4 |
|---|---|
| UPC | 681344941473 |
| Product Height (in) | 3.7 |
| Product Length (in) | 9.7 |
| Product Width (in) | 5.8 |
| Warranty | 1 Year |
| Weight (lbs) | 2.0000 |
